PTFE

PolyTetraFluorEthylene

SCROLL

PTFE is a semi-crystalline fluoroplastic with exceptionally high chemical and thermal resistance (-200 to +260°C, up to 300°C for short periods).


Additionally, this thermoplastic material demonstrates outstanding sliding properties, an anti-adhesive surface, and top insulation properties. It is, however, subject to low mechanical strength and a high specific weight in comparison to other plastics. PTFE can be provided as a compound with extenders such as glass fibres, carbon, or bronze to improve its mechanical properties. Due to its structure, this material is formed as a semi-finished product in press processing and then machined.

PTFE Properties
  • Very good sliding properties (lowest friction value of all hard materials)
  • Can be used in a very broad range of temperatures (-200°C to +260°C)
  • Very good chemical resistance
  • Resistant to hydrolysis and hot steam
  • No absorption of moisture
  • Physiologically safe (BGA and FDA approved)
  • Very good UV resistance
  • Very good dampening properties
  • Good electrical insulation capacity (unfilled type)
  • Average mechanical strength
PTFE Data Sheet
Data Sheet (PDF)

Product Variants

Please click on the product variant for details

= increased creep rupture strength

Data Sheet (PDF)

= increased creep rupture strength

Data Sheet (PDF)

= wear reduction, antistatic

Data Sheet (PDF)

= conductive of static, approved by food law

Data Sheet (PDF)

= higher mechanical load capacity and low coefficient of linear expansion, FDA approved

Data Sheet (PDF)

= higher mechanical load capacity and low coefficient of linear expansion

Data Sheet (PDF)

= increased creep strength, wear resistance and thermal conductivity

Data Sheet (PDF)

= increased creep strength, wear resistance and thermal conductivity

Data Sheet (PDF)

= increased abrasion resistance and emergency running properties of plain bearings

Data Sheet (PDF)

= enhanced mechanic properties

Data Sheet (PDF)
Please read our important notes on data sheets! You can find these under the MATERIALS section under USEFUL INFORMATION where we provide more detail on our data sheets, tolerances, and more.
